Parking Pawl Missing on Transmission – 2022 Isuzu FTR

“This site contains affiliate links for which OEMDTC may be compensated”

July 11, 2022 NHTSA CAMPAIGN NUMBER: 22V497000

Parking Pawl Missing on Transmission

There is no pawl to engage when the transmission shift lever is set to the park position, which could lead to the truck rolling away, increasing the risk of a crash.



NHTSA Campaign Number: 22V497

Manufacturer Isuzu Motors Limited

Components POWER TRAIN

Potential Number of Units Affected 4



Summary

Isuzu Motors Limited (Isuzu) is recalling certain 2022 FTR vehicles equipped with Allison 2500RDS (FVR) transmissions. The transmission is missing the parking pawl.



Remedy

Dealers will replace the 2500RDS (FVR) transmission with a 2550RDS (FTR) transmission, free of charge. Owner notification letters are expected to be mailed on August 12, 2022. Owners may contact Isuzu’s customer service at 1-866-441-9638. Isuzu’s number for this recall is V2203.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.



Check if your Isuzu Truck has a Recall




BULLETIN NUMBER:
CB22-K-001

ISSUE DATE:
AUGUST 2022



INCORRECT TRANSMISSION INSTALLED – 22V-497



AFFECTED VEHICLES

2022MY Isuzu FTR



CONDITION

Isuzu Motors Limited has decided that a defect, which relates to motor vehicle safety, exists in certain 2022MY Isuzu FTR vehicles. The affected FTR vehicles were erroneously built with the 2022 MY FVR (Class 7 truck) transmission, which does not have a parking pawl. When the transmission shift lever is set to the Park “P” position in the PRNDL, there is no parking pawl inside the transmission to engage the Park position. If the parking brake is not applied in this condition, the truck can roll away, which could lead to a crash.



CORRECTION

An Isuzu dealer will replace the existing transmission with the correct and new 2022MY FTR (Class 6 truck) transmission, which includes the parking pawl. This service will be performed free of charge.



VEHICLES INVOLVED

Involved are 2022MY Isuzu FTR vehicles (See VIN List above).
Important: Dealers are to confirm vehicle eligibility prior to beginning repairs by using IVIS (Isuzu Vehicle Information System).



PARTS INFORMATION

The Allison Transmission must be requested when the customer appointment is set or when the affected vehicle arrives at your location, whichever occurs first. Request the replacement transmission by sending an email to ICTA.Warranty@icta-us.com. In the subject line for the email, please type “22V-497 Allison Part Request”. In the body of the email, please include the following information pertaining to the subject vehicle:

  • VIN
  •  Mileage (approximate is OK)
  • Appointment Date for the repair. If the vehicle is already at your dealership, please state that in the email
  • Preferred shipping address
  • Contact name
  • Contact phone number.

These details are required to ensure the replacement transmission is shipped to the correct location.



SERVICE PROCEDURE

1. Follow the service procedure for “Transmission Replacement” in the “Transmission” section of the Service Manual for the 2022MY FTR to replace the Allison transmission assembly.




DET-22-087

Chronology of Defect / Noncompliance Determination

573.6 (c) (6) (7)

Describe the chronology of events leading up to the defect decision or test data for the noncompliance decision:

On March 21, 2022, Isuzu received the first field case reporting a Class 6 FTR model truck that continued to move when the transmission shift lever was placed in the Park (“P”) position.

Isuzu North America Corporation (INAC) QA, together with Isuzu Motors Limited (IML),  Isuzu Technical Center of America, Inc. and Isuzu Commercial Truck of America, Inc.  (collectively, Isuzu), promptly launched an investigation and determined that the truck was built with a 2500RDS transmission that was intended for a Class 7 FVR model truck.  The 2500RDS transmission does not have a parking pawl by design; however, the 2550RDS transmission that is intended for the Class 6 FTR model truck does have a parking pawl, and the transmission shift lever in these trucks has a Park position.

Isuzu determined that the end of assembly line Dynamic Vehicle Test booth (DVT) had a flaw in its logic such that it did not properly detect whether the correct transmission was installed in each truck. The software for the DVT detection logic was upgraded and corrected on March 23, 2022. Based on a factory check of the transmissions in the factory’s inventory conducted on March 22, 2022, Isuzu’s understanding was that the vehicle that was the subject of the March 21 field case was likely the only FTR that had the wrong transmission. Having received no further reports from the field concerning or documenting this issue, Isuzu closed its investigation on May 5, 2022. (Note that the vehicle that was the subject of the March 2022 field report was repaired in April 2022 and retailed by an Isuzu dealer on or about May 6, 2022.)

On May 20, 2022, Isuzu received word of a second Class 6 FTR truck in the field that was found to have rolled after the transmission shift lever was placed in the Park position.  A formal field report, which confirmed that the FTR vehicle in question had the wrong transmission (one with no parking pawl) installed, was prepared on May 26, 2022; and Isuzu reopened its investigation the same day.

The investigation determined that vehicle build records documented the serial number of the transmission that was installed in the F-Series vehicles. On June 23, 2022, INAC QA was able to obtain a list that matched specific VINs with specific transmission serial numbers. It then took until June 28 to input each specific transmission serial number (one by one) into a tool on the Allison website that provided the transmission model number (2550RDS or 2500RDS) of each serial number. Because Allison has its own proprietary tool that can match its transmission serial and model numbers more quickly, Isuzu also sent the list of serial numbers to Allison on June 23, but did not receive the results of Allison’s independent search until June 28. Fortunately, Allison’s search results matched Isuzu’s search results. In total, Isuzu determined that there were three (3) Class 6 FTR trucks that had been built with the wrong transmission and released from Isuzu’s control: two were the vehicles that were the subject of the March and May 2022 field reports (which vehicles had already been repaired and retailed) and one FTR was still owned by an Isuzu dealer. On or about June 29, Isuzu contacted that dealer and instructed that dealer not to sell or deliver that vehicle until the transmission could be replaced.

On July 1, 2022, Isuzu made a decision to conduct a safety-related defect recall. The recall will include the one FTR still owned by the Isuzu dealer as well as the two FTR trucks that were the subject of the two field reports mentioned above. Those two vehicles were repaired and no longer have the safety defect in question, but they are being included so that they can be equipped with new 2550RDS Allison transmissions in place of the repaired or remanufactured transmission they received previously. [In addition, Isuzu has determined that there is one additional FTR for which the build records show an inaccurate serial number. As a result, Isuzu has not been able to determine whether the vehicle has the correct or wrong model transmission. For that reason, this additional vehicle will be included in this recall.]

Isuzu is not aware of any crashes, property damage, injuries or deaths associated with this issue.




1 Affected Product

Vehicle

MAKE MODEL YEAR
ISUZU FTR 2022




13 Associated Documents

Recall Acknowledgement

RCAK-22V497-9418.pdf 645.998KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [630.86 KB]




Miscellaneous Document- Chronology

RMISC-22V497-9551.pdf 93.051KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [90.87 KB]




Defect Notice 573 Report

RCLRPT-22V497-4406.PDF 215.259KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [210.21 KB]




Recall 573 Report- 07/20/2022

RCLRPT-22V497-3160.PDF 215.279KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [210.23 KB]




Remedy Instructions and TSB

RCRIT-22V497-0271.pdf 230.762KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [225.35 KB]




ISSUED Owner Notification Letter(Part 577)

RCONL-22V497-3210.pdf 231.272KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [225.85 KB]




Manufacturer Notices(to Dealers,etc)

RCMN-22V497-1931.pdf 122.949KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [120.07 KB]




Manufacturer Notices(to Dealers,etc)

RCMN-22V497-8611.pdf 285.552KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [278.86 KB]




Recall 573 Report- 09/14/2022

RCLRPT-22V497-3884.PDF 243.594KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [237.88 KB]




Recall 573 Report- 09/22/2022

RCLRPT-22V497-8253.PDF 215.281KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [210.24 KB]




Recall Quarterly Report #1, 2022-3

RCLQRT-22V497-0164.PDF 211.127KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.18 KB]




Recall Quarterly Report #2, 2022-4

RCLQRT-22V497-3788.PDF 211.222KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.27 KB]




Recall Quarterly Report #3, 2023-1

RCLQRT-22V497-7539.PDF 211.302KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.35 KB]




Latest Recalls Documents

For the Latest and Most Recent Recalls Information Visit the link below…

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=22V497&docType=RCL
