November 20, 2020 NHTSA CAMPAIGN NUMBER: 20V720000
Positive Battery Cable To Starter Too Long
Over time, heat from the exhaust pipe may cause the conduit and insulation to deteriorate, exposing the wires, possibly causing a short circuit which could result in a no-start condition or a fire.
NHTSA Campaign Number: 20V720
Manufacturer Isuzu Technical Center of America, Inc.
Components ELECTRICAL SYSTEM
Potential Number of Units Affected 46
Summary
Isuzu Technical Center of America, Inc. (Isuzu) is recalling certain 2020 Isuzu NPR-HD Gas (Crew Cab) and 2020 Chevrolet 4500 (Crew Cab) trucks equipped with 6.6L gasoline engines. The positive cable connecting the battery to the starter may be too long and may have been routed too close to the right-side exhaust pipe.
Remedy
Isuzu and Chevrolet will notify their respective vehicle owners and dealers of this recall, and specifically of the need to adjust the positive cable in subject vehicles, and owners will be informed that the recall repairs will be done free of charge. The recall began December 11, 2020. For additional information, Isuzu owners may contact Isuzu Customer Relations at 1-866-441-9638 and Chevrolet owners may contact the GM Medium Duty Truck assistance line at 1-800-862-4389. Isuzu’s number for this recall is V2005.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.
Check if your Isuzu Truck has a Recall
CONDITION
Isuzu Motors Limited has decided that a defect, which relates to motor vehicle safety, exists in certain 2020MY N-Series crew cab vehicles with gasoline engines 6.6 L8T (see VIN list). In the subject vehicles, the positive cable connecting the battery to the starter was too long. Depending on the installation positioning, the cable may have been routed too close to the right-side exhaust pipe. Over time, heat from the exhaust pipe may cause the conduit and insulation to deteriorate, which may expose the wires and lead to the potential for a short circuit. Exposed wires could corrode and/or short circuit, resulting in a no-start condition or thermal event, increasing the risk of a crash or fire.
CORRECTION
Isuzu dealers are to adjust the positive cable away from the exhaust pipe. This service will be performed free of charge.
SERVICE PROCEDURE
1. Shift vehicle to park, turn off engine, set parking brake, and block rear wheels.
2. Locate the “P” clamp that secures the positive battery cable harness beneath the air cleaner. (See Figures 1 and 2.)
3. Loosen the “P” clamp hold down bolt and remove it. (See Figure 3.) Spread the “P” clamp apart so it can be easily relocated on the positive battery cable harness. (See Figure 4.)
4. Move the positive battery cable harness forward (toward the front of the vehicle) 55mm. (See Figure 5.) The “P” clamp should now be located 55mm rearward of the white tape on the positive battery cable harness. (See Figure 6.)
5. Squeeze the “P” clamp tight when the positive battery harness is forward 55mm. Install the “P” clamp hold down bolt and tighten to 10 Nm (7 ft.lb.).
6. Check to confirm the positive battery cable does not hang lower than the air cleaner mounting bracket. (See Figure 9.) Loosen the “P” clamp and adjust if necessary.
STOP SALE AND DELIVERY – SAFETY RECALL
Date: November 20, 2020
Subject: Stop Sale and Delivery for Upcoming Safety Recall
Affected Models:
- Certain 2020MY N-Series Crew Cab Vehicles with Gasoline Engines 6.6 L8T
To: Isuzu Dealer Principal, Sales Manager and Service Manager
Effective immediately, stop the sale and delivery of affected vehicles in your inventory, even if a customer has purchased an affected vehicle. We are in the process of taking steps to address a safety related defect in these vehicles. Federal law prohibits the sale and delivery to customers of any vehicle containing a safety defect. You must not deliver any covered vehicles to customers until after the vehicle has been remedied.
WHAT IS THE CONDITION
Isuzu Motors Limited has decided that a defect, which relates to motor vehicle safety, exists in certain 2020MY N-Series crew cab vehicles with gasoline engines 6.6 L8T. In the subject vehicles, the positive cable connecting the battery to the starter was too long. Depending on the installation positioning, the cable may be routed too close to the right-side exhaust pipe. Over time, heat from the exhaust pipe may cause the conduit and insulation to deteriorate, which may expose the wires and lead to the potential for a short circuit. Exposed wires could corrode and/or short circuit, resulting in a no-start condition or a thermal event, increasing the risk of a crash or fire.
WHAT WE WILL DO
Isuzu Commercial Truck of America, Inc. has issued this notice and, if applicable, an affected inventory report (approximately 24 vehicles are in dealer inventory). On Monday, November 23, 2020 the campaign bulletin will be published.
WHAT YOU SHOULD DO
After confirming there are affected vehicles in your dealer’s inventory, using the Isuzu Vehicle Information System (IVIS), open a repair order referencing this Stop Sale for each affected NEW vehicle in your inventory and hold the vehicle until the campaign bulletin is released.
IMPORTANT: Always confirm vehicle eligibility prior to beginning repairs by using the Isuzu Vehicle Information System (IVIS).
You will receive information about owner notification in the near future.
We regret any inconvenience this action may cause you.
Sincerely,
Isuzu Commercial Truck of America, Inc.
Isuzu Commercial Truck of America, Inc.
Customer Relations Department
1400 S. Douglass Road, Suite 100, Anaheim, CA 92806 *1-866-441-9638
DOC ID: SS_V2005_20201120
SEOCONTENT-START
IMPORTANT SAFETY RECALL
POSITIVE BATTERY CABLE ADJUSTMENT – 20V-720
Certain 2020MY N-Series Crew Cab Vehicles with Gasoline
Engines 6.6 L8T (see VIN list)
This bulletin supersedes service bulletin CB20-N-004. This bulletin is being revised
to include the sample US owner letter. Please discard previous bulletin CB20-N-004.
AFFECTED VEHICLES
INFORMATION
IMPORTANT SERVICE
INFORMATION FOR:
SERVICE MANAGER
SERVICE ADVISOR
TECHNICIAN
PARTS DEPARTMENT
WARRANTY PERSONNEL
BULLETIN NUMBER:
CB20-N-004A
ISSUE DATE:
DECEMBER 2020
GROUP:
ELECTRICAL
CV
VEHICLES INVOLVED
Certain 2020MY N-Series crew cab vehicles with gasoline engines 6.6 L8T. See below affected
VINs.
54DC4J1D0LS207212 54DC4J1D3LS207284 54DC4J1D5LS207660
54DC4J1D0LS207288 54DC4J1D3LS207611 54DC4J1D6LS207781
54DC4J1D0LS207811 54DC4J1D3LS207639 54DC4J1D7LS207286
54DC4J1D1LS207283 54DC4J1D3LS207642 54DC4J1D8LS207216
54DC4J1D1LS207607 54DC4J1D3LS207737 54DC4J1D8LS207815
54DC4J1D1LS207610 54DC4J1D4LS207214 54DC4J1D9LS207211
54DC4J1D1LS207638 54DC4J1D4LS207813 54DC4J1D9LS207287
54DC4J1D1LS207641 54DC4J1D5LS207285 54DC4J1DXLS207783
54DC4J1D1LS207784 54DC4J1D5LS207609 54DC4J1DXLS207816
54DC4J1D2LS207213 54DC4J1D5LS207612
Important: Dealers are to confirm vehicle eligibility prior to beginning repairs by using IVIS
(Isuzu Vehicle Information System).
For dealers with involved vehicles, an assigned vehicle report containing the complete vehicle
identification numbers has been provided. Dealers will not have a report available if they have
no involved vehicles currently assigned.
Figure 9
7. Proceed to Applying the Campaign Label.
Good
No Good
APPLYING THE CAMPAIGN LABEL
8. Using a ball-point pen, fill in a campaign label (Part No. 2-90028-700-0) with Campaign
Number 20V-720, Isuzu dealer code, and repair date.
9. Affix the campaign label onto the driver’s side B-pillar.
Refer to the Isuzu ICS Claims Processing Manual for details on Campaign Claim Submission.
Submit only one claim as indicated below.
Labor
Operation Code
Description Labor Time
V2005 Positive Battery Cable Adjustment 0.3
*Includes 0.1 hours for administrative allowance.
DEALER RESPONSIBILITY
Dealers are to service all vehicles subject to this campaign at no charge to customers, regardless
of mileage, age of the vehicle, or ownership. Customers who have recently purchased vehicles
sold from your vehicle inventory, and for which there is no customer information indicated on the
dealer listing, are to be contacted by the dealer. Arrangements are to be made to perform the
required correction according to the instructions contained in this bulletin. Program follow-up
cards should not be used for this purpose, since the customers may not as yet have received
the notification letter.
In summary, whenever a vehicle subject to this campaign enters your vehicle inventory, or is in
your dealership for service, you must take the steps necessary to ensure the recall remedy has
been implemented before selling or releasing the vehicle.
Important:
As required by Federal law, dealers are not to deliver any new vehicle in their inventory, which
is covered by a Safety Recall, until the necessary remedy has been performed.
Dealers are to confirm vehicle eligibility prior to beginning repairs by using IVIS (Isuzu Vehicle
Information System). Not all vehicles may be involved.
OWNER NOTIFICATION
The sample recall letter that will be sent to owners of affected vehicles already retailed in the
United States is attached below.
CLAIM INFORMATION
[SAMPLE OWNER LETTER – US]
IMPORTANT SAFETY RECALL
NHTSA Recall 20V-720
This notice applies to your vehicle, <VIN>
DECEMBER 2020
Dear Customer,
This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act. Your vehicle
<VIN> 2020 model year Isuzu N-Series is involved in safety recall NHTSA 20V-720.
WHAT IS THE CONDITION?
Isuzu Motors Limited has decided that a defect, which relates to motor vehicle safety, exists in certain 2020MY NSeries
crew cab vehicles with 6.6L gasoline engines. In the subject vehicles, the positive cable connecting the
battery to the starter was too long. Depending on the installation positioning, the cable may be routed too close to
the right-side exhaust pipe. Over time, heat from the exhaust pipe may cause the conduit and insulation to deteriorate,
which may expose the wires and lead to the potential for a short circuit. Exposed wires could corrode and/or short
circuit, resulting in a no-start condition or a thermal event, increasing the risk of a crash or fire.
WHAT WE WILL DO
Isuzu dealers will adjust the positive cable away from the exhaust pipe. This service will be performed free of
charge.
WHAT YOU SHOULD DO
We recommend that you contact your Isuzu dealer to schedule an appointment. Although not necessary, please
present this Owner Notification Letter at the time of your appointment or refer to Campaign Service Bulletin CB20-
N-004A. We estimate that the repair may take up to 18 minutes to perform. However, additional time may be
necessary due to the dealer’s schedule. To locate the nearest Isuzu dealer you can visit our website at
www.isuzucv.com or contact our Customer Relations Department at the number listed below.
Isuzu Commercial Truck of America
Customer Relations
1-866-441-9638
If you have any difficulty having this recall performed, we recommend that you call Isuzu customer relations at 1-
866-441-9638. If you are still not satisfied that we have remedied this situation without charge, and within a
reasonable amount of time, you may wish to write to the Administrator of the National Highway Traffic Safety
Administration, 1200 New Jersey Avenue, SE, Washington DC 20590, or call the agency’s toll-free Vehicle Safety
Hotline at 1-888-327-4236 (TTY: 1-800-424-9153), or go to www.nhtsa.gov.
We regret any inconvenience which this action may cause you.
Sincerely,
Isuzu Commercial Truck of America, Inc.
Important: If you have sold or traded your Isuzu vehicle, please enter the owner’s name and address, if known, on the attached “Change
of Information” postcard, tear off at both perforations, and drop it in the mail. Postage has already been paid. We will contact the new
owner.
Federal law requires that any vehicle lessor receiving this recall notice must forward a copy of this notice to the lessee within ten days.
Lessor means a person or entity that is the owner, as reflected on the vehicle title, of any five or more leased vehicles.
SEOCONTENT-END
2 Affected Products
Vehicles
MAKE | MODEL | YEAR |
CHEVROLET | LOW CAB FORWARD 4500 | 2020 |
ISUZU | NPR HD | 2020 |
11 Associated Documents
Owner Notification Letter(Part 577)
RCONL-20V720-9528.pdf 260.214KB
Manufacturer Notices(to Dealers,etc)
RCMN-20V720-6334.pdf 111.622KB
Recall Acknowledgement
RCAK-20V720-1533.pdf 244.706KB
Defect Notice 573 Report
RCLRPT-20V720-7258.PDF 216.789KB
Manufacturer Notices(to Dealers,etc)
Recall Quarterly Report #1, 2020-4
RCLQRT-20V720-2205.PDF 211.15KB
Remedy Instructions and TSB
RCRIT-20V720-8802.pdf 1505.459KB
Manufacturer Notices(to Dealers,etc)
RCMN-20V720-8501.pdf 106.827KB
Recall Quarterly Report #2, 2021-1
RCLQRT-20V720-1280.PDF 211.251KB
Recall Quarterly Report #3, 2021-2
RCLQRT-20V720-6109.PDF 211.333KB
Recall Quarterly Report #4, 2021-3
RCLQRT-20V720-6281.PDF 211.435KB
Latest Recalls Documents
For the Latest and Most Recent Recalls Information Visit the link below…
https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=20V720&docType=RCL
- COPPER CLAD ALUMINUM (CCA) - Our primary cable CCA wire is the most economical option for choosing power or ground wire and is a great conductor of power. Copper coated aluminum gives you an economic power cable with excellent power transfer. Systems that require more power should use ofc cable wiring.
- POWER / GROUND WIRE SET - Our bundled power wire set is great for a car amplifier or subwoofer or to be used as a ground wire on your electric wire installs. Use for many different applications such as indoor lighting, car radio, automotive, lighting, car speakers, power cables, 12v power inverter, ground wire, or welding cable.
- SOFT TOUCH JACKET FOR BETTER HANDLING - Mechanics and construction workers will appreciate the fully insulated, soft touch jacket around each copper clad aluminum wire, making it safe and easy to handle on build sites, in automotive garages and at marine jobs. The jacket is simultaneously durable and flexible, great for tucking into sharp corners under the hood.
- EASY POLARITY IDENTIFICATION - Easy color coded ground wire helps with installation to let you know which cable should connect to the terminal. Making a polarity error could cause serious damage to your audio equipment.
- WIDE COMPATIBILITY - Also known as power wire, ground wire, trolling motor wire, automotive wire, speaker wire, car radio wire, amp wire, electrical wire, or welding wire designed for up to 300v voltage. We have many gauge wires to choose from, such as 1/0awg, 4awg, 8awg with black, red, blue wire color options and 25ft, 50ft lengths
- 4 AWG wire, fits 3/8" stud, SAE 4 GAUGE COPPER
- Zinc plated 95% copper lugs for superior corrosion and oxidation resistance
- Better stamping process to improve the current and reduce the resistance.
- Boat cable wire stays ultra flexible even in the most extreme conditions
- Heat-resistant up to 105C
- 1/0 GAUGE 20-FEET(6m) OF EACH COLOR BLACK & RED CCA POWER GROUND WIRE - The lower the gauge number, the thicker the wire. Thicker wire presents less resistance to current flow. Copper coated aluminum gives you an economic power cable with excellent power transfer.
- HIGH QUALITY MATERIALS - High quality stranded CCA wire offers strong power transfer performance, while remaining lightweight with maximum flexibility.Oxygen Free Coppe(OFC) wiring provides a superior electrical conductor to aluminum because it does not expand or contract with heat and can carry a higher current load.
- RUGGED PVC JACKET - Low memory, flexible soft-touch jacket material is perfect for routing in hard to reach places,designed for the electrical and auto repair installer in mind. Strong, yet durable pvc jacket has has flexibility, elasticity, and impact resistance built in,is resistant to extreme temperatures, liquid, oil, gas, abrasions and high impact.
- PACKAGE - 2 pcs 1/0 gauge black/red CCA power ground wire(20 feet of each color);10pcs 1/0 AWG-3/8" Battery Lugs;10pcs 1/0 AWG-5/16" Battery Lugs;20pcs 3:1 Dual Wall Adhesive Heat Shrink Tubing.
- WIDE COMPATIBILITY - Our bundled power wire set is great for a car amplifier or subwoofer or to be used as a ground wire on your electric wire installs. Use for many different applications such as indoor lighting, car radio, automotive, lighting, car speakers, power cables, 12v power inverter, ground wire, or welding cable.
- TURE 4 AWG GAUGE BLACK&RED POWER/GROUND WIRE-TopstrongGear 4 gauge 50-feet (15.24m) red & black power/ground wire meets American Wire Gauge(AWG) standard, offering true-to-gauge quality that guarantees the necessary power flow for your wiring projects. Thicker wire presents less resistance to current flow.
- PREMIUM COPPER-CLAD ALUMINUM (CCA) WIRE CONTAINS 30% COPPER- Ensuring robust power transfer in a lightweight design. TopstrongGear CCA with 30% OFC wires maintain maximum flexibility while providing the strength needed for efficient power transfer at an affordable price point. For specific power demands, explore our range of premium Oxygen-Free Pure Copper (OFC) wiring alternatives.
- SOFT-TOUCH PVC JACKET MAXIMIZING FLEXIBILITY AND DURABILITY- TopstrongGear true spec 4 gauge wires come with a rugged PVC jacket, offering both flexibility and durability for challenging placements. Its soft-touch design suits electrical and auto repair installations, providing indoor use versatility with built-in resilience to impacts and diverse conditions. Extreme Heat Tested
- SIMPLIFIES POLARITY IDENTIFICATION -Easy color coded power and ground wires, ensuring easy connection to the correct terminals during installation. This prevents potential damage to your audio equipment that could result from polarity errors. The differently colored jackets serve as a visual guide, facilitating easy polarity identification and safeguarding against potential damages caused by incorrect connections.
- WIDE COMPATIBILITY- Dedicated to offering top-notch wiring solutions for a variety of projects, including car audio systems, home stereos, RV trailers, solar panel installations, and more. Please note, the gauge should be used appropriately, and TopstrongGear is not liable for improper use.Grade A- CCA Power Wire
- Sold as a set: 2 gauge battery cable, includes 1x positive(red) and 1x negative(black) cable. Length: 2ft, Gauge: 2AWG, fits 3/8" stud.
- Durable material: The copper 2 gauge battery cable lugs are tinned coated, well crimped, and utilize a closed end design for corrosion protection.Heat-resistant up to 105C.
- Easy to connect: These flexible 2 gauge battery cable are made with thinly stranded pure copper, making them easy to handle an install ,It can also be used normally in extreme environments.
- Use for: Marine battery cables are to withstand harsh environments. 2 gauge battery cable is ideal for various equipments, inverter batteries, cars, solar energy, RV, boat, etc.
- Warranty: 1 year warranty, 30 days worry-free return, if you have any questions, our customer service will be online 24 hours a day. You can buy our 2 gauge battery cable with confidence.
- Fit for Automotive Solar Marine Boat RV Car Motorcycle
- 4 gauge battery/welding cable with 3/8 " lugs; Battery Cable Length: 5 Feet
- Package will come with each one of the red and black cable, each cable end is sealed with heat shrink tubing for heat insulation
- Copper Cable lugs are made of solid copper with a tin plating cover for corrosion protection
- Please feel free to contact us if you have any questions about our products, your satisfaction would be our greatest motivation
- COPPER CLAD ALUMINUM (CCA) - Our primary cable CCA wire is the most economical option for choosing power or ground wire and is a great conductor of power. Copper coated aluminum gives you an economic power cable with excellent power transfer. Systems that require more power should use ofc cable wiring.
- POWER / GROUND WIRE SET - Our bundled power wire set is great for a car amplifier or subwoofer or to be used as a ground wire on your electric wire installs. Use for many different applications such as indoor lighting, car radio, automotive, lighting, car speakers, power cables, 12v power inverter, ground wire, or welding cable.
- SOFT TOUCH JACKET - Soft touch jacket design designed for the electrical and auto repair installer in mind. Strong, yet durable pvc jacket that is best for indoor use but has flexibility, elasticity, and impact resistance built in.
- EASY POLARITY IDENTIFICATION - Easy color coded ground wire helps with installation to let you know which cable should connect to the terminal. Making a polarity error could cause serious damage to your audio equipment.
- WIDE COMPATIBILITY - Also known as power wire, ground wire, trolling motor wire, automotive wire, speaker wire, car radio wire, amp wire, electrical wire, or welding wire designed for up to 300v voltage. We have many gauge wires to choose from, such as 1/0awg, 4awg, 8awg with black, red, blue wire color options and 25ft, 50ft lengths
- 2 gauge battery/welding cable with 3/8 " lugs
- Can be used on variety of applications, such as automotive, solar, marine, boat, rv, car, motorcycle, etc
- The battery cable is made of high quality PVC insulation sheath, each cable end is sealed with heat shrink tubing for heat insulation
- Copper Cable lugs are made of solid copper with a tin plating cover for corrosion protection
- Please carefully check all the product information to make sure this is the right one you want before placing an order
- Premium Material: Battery Cable is made of Copper, which has good electrical conductivity.
- Wide Applications: Battery Cable can be used for car, vehicle, RV, Truck, solar application, boat, etc.
- Durable & Safe: The exterior of the Battery Cable is made of premium PVC insulated jacket, which has good thermal insulation.
- Easy to use: The battery cables with two ring terminals that can be used to connect the battery disconnects/switch. The copper wires prevent corrosion and allow for more easily soldering.
- What you get: 2PCS Copper Battery Cables.
- 【Complete Kit】- You will get a battery cable wire lug crimping tool, a cable cutter, 170pcs copper ring terminal block, 210pcs heat shrinkable tube, the size and quantity are complete to meet your various needs.
- 【10-1/0 Lug Crimper】- Professional cable terminal crimping tools are 6mm²/10mm²/16mm²/25mm²/35mm²/50mm² (similar to AWG 10, 8, 5, 3, 2, 0). It uses high-precision jaws to ensure a tight connection after crimping.
- 【Electrolytic Grade Copper】- All ring terminals are made of electrolytic grade copper to achieve maximum conductivity. The heat shrinkable tube is made of high-quality polyethylene material, which is thick and durable.
- 【Labor-saving Crimping】- The handle of the crimping device is up to 10" long and is wrapped with soft rubber. The ergonomic lever structure design can increase friction and make you more labor-saving when crimping.
- 【Heat Shrinkable Tube】- The heat shrinkable tube is made of high-quality polyethylene material, which is thick and durable.
Last update on 2024-03-29 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
